HM Digital DM-2EC: Commercial Inline Dual EC Monitor
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| MPN | DM-2EC |
| Compatible Model | None |
| Model | DM-2EC |
| Brand | HM Digital |
| Color | White |
Inline ELECTRICAL CONDUCTIVITY monitor that can be installed on industrial water filtration systems such as car washes, window washing, manufacturing, and food processing. FEATURES Highly efficient and accurate due to its advanced microprocessor technology. Displays EC levels of the Feed Water and Product Water with in & out electrode probes. Auto-Off function conserves battery power. The unit shuts off automatically after 3 minutes. Dual Range - Measures from 0-999 µS, with a resolution of 1 ppm. From 1000 to 9990 µS, the resolution is in 10 µS increments, indicated by a blinking 'x10' image. Factory Calibrated :calibrated to 1413 µS. The DM-2EC features digital calibration. Diagnostic error messaging Shielded sensor cables Comes equipped with 1/4 inch Mur-lok® Quick-Connect T-fittings. Also available with 3/8" or 1/2" fittings. Installs quickly and easily. Differences from the DM-1: Measures EC (Electrical Conductivity) in µS (micro-Siemens). Designed for commercial/industrial applications. Stronger, water-resistant casing. Digital calibration can be done individually on each line. Improved design, including an extra large, easy-to-read LCD display. Longer, waterproof, shielded cables. Variable mounting bracket. SPECIFICATIONS Range: 0-9990 µSAccuracy: ±2% Cable Length: 46" (including sensor), shielded cablesSensor: Dual, 1/4" diameter for quick-connect fittings (model SP-3, included)Digital Calibration: Digitally factory calibrated to 1413 µS. Re-calibration can be done separately for each line. Power source: 2 x AA batteries (included) Battery life: Approx. 2 years Size: 11.6 x 6.8 x1.8 cm (4.6 x 2.6 x .7in.) Weight: 201.3 g (7.1 oz.)
